POLEHP HP Hinged Poles
PRICING: Due to the ever-changing economic environment, please consult the factory for pole quotes. ADDITIONAL NOTE: Fixtures and arms must be mounted to the pole before it is erected. Failure to do so may cause the pole to experience the rare, but damaging phenomenon of harmonic vibrations and fatigue. Failure to do so will void the factory warranty.
For Reference Only: The ASCE 7 Hazard Tool is the official source of information for pole selection when identifying wind speed zone limits within North America.
https://asce7hazardtool.online/
For Reference Only: The ASCE 7 Hazard Tool is the official source of information for pole selection when identifying wind speed zone limits within North America.
https://asce7hazardtool.online/
Downloads
EPA Comparison
Wind Zone Map
HP 15 4 11 11 Spec
HP 20 4 11 11 Spec
HP 20 4 7 11 Spec
HP 20 5 11 11 Spec
HP 20 5 7 11 Spec
HP 25 4 7 7 Spec
HP 25 4 7 11 Spec
HP 25 5 11 11 Spec
HP 25 5 7 11 Spec
HP 30 5 7 11 Spec
HP 30 6 7 7 Spec
Installation Instructions
Pole
The pole shaft is fabricated from hot rolled carbon steel having a minimum
yield of 55,000 PSI and conforms to ASTM A500 grade C requirements.
The shaft construction is two pieces of formed steel welded longitudinally
connect by an internal hinge. The hand hole is located 1’ 6" above the pole
base. A ground lug is provided standard. Winch ordered separately.
Anchor Base
The anchor base is fabricated from a structural quality hot rolled carbon
steel plate that has a minimum yield strength of 36,000 PSI. The anchor
base telescopes the pole shaft and has a circumferential weld on the top
and bottom.
Base Cover
A full base cover is provided which encapsulates the base plate and anchor
bolts to provide a clean transition from pier to pole.
Finish
The pole is finished with a Super Durable Powdercoat Paint. Multiple
colors available. Galvanizing and T-Guard treatments available upon
request. Additional warranty extensions available with these treatments.
